Specially manufactured for use in WeatherDeck™ Waterproof Panels
Rated IP67 - temporary immersion for 30 minutes, when mounted with a WeatherDeck™ Toggle Switch Boot (8-24138)
Nickel-plated brass & phenolic non-corrosive construction
Specifications Single Pole
- Rating: 250 Volts AC: 10 Amps
- Rating: 125 Volts AC: 15 Amps
- Rating: 12 Volts DC: 15 Amps
- Terminal Size: 0.25" (6.35mm)
- Terminal Type: Quick Connect Tab
- Specifications Double Pole
- Rating: 30 Volts DC: 5 Amps
- Terminal Size: 0.25" (6.35mm)
- Terminal Type: Quick Connect Tab
